TECH SPECS
Pure. Focused. Performance.
ENGINE & TRANSMISSION
Type
Single Cylinder, 4-stroke, DOHC
Capacity
249.95 cc
Bore
78 mm
Stroke
52.3 mm
Compression
14.4
Max power
47.3 PS / 47.4 bhp (35.3 kW) @ 13,250 rpm
Max Torque
28.3 Nm (21.1 lbft) @ 9,250 rpm
System
Dell’Orto throttle body, Athena EMS
Exhaust
Single silencer
Final drive
Chain, 13T/48T
Clutch
Wet, multi-plate, spring (Belleville)
Gearbox
5 Speed
CHASSIS
Frame
Spine and double cradle, aluminium
Swingarm
Aluminium fabrication
Front wheel
21” x 1.6”
Rear wheel
19” x 1.85”
Front tyre
80/100-21
Rear tyre
100/90-19
Front suspension
KYB 48 mm coil spring fork, compression and rebound adjustment, 310 mm wheel travel
Rear suspension
KYB coil, compression adjustment (high and low speed), rebound adjustment, 305 mm wheel travel
Front brakes
Twin, 260 mm disc, Brembo, twin-piston floating caliper (2 x 24 mm pistons)
Rear brakes
Single, 220 mm disc, Brembo, 26 mm single-piston floating caliper
Instruments
Hour meter, multi-function switch cubes
DIMENSIONS & WEIGHTS
Width
836 mm
Height
1270 mm
Seat height
960 mm
Wheel base
1492 mm
Rake
27.4 °
Trail
116 mm
Wet weight
104 kg
Fuel capacity
7 l
STANDARD EQUIPMENT
- D.I.D. DirtStar aluminium wheels
- Dual engine maps
- Exedy Clutch with Brembo Hydraulic Actuation
- Galfer discs
- Handlebar-Mounted Control Switch
- KYB AOS Suspension (Front & Rear)
- Launch control
- Neken Yokes & Pro Taper ACF Carbon Core Bars
- ODI grips
- Pirelli MX32 Tyres
- Quickshifter
- Sensor Dashboard + Hour Meter
- Traction control
- Athena ECU Engine Management System
OPTIONAL ACCESSORIES
- Akrapovič titanium silencer
- Brake disc guard
- Gripper seat options
- LC-GPA launch control module
- Low seat
- Machined aluminium fuel cap
- Washable TwinAir filters
- WiFi tuning module
- Accessory plastic kit
Forged Performance Internals
König forged piston, Del West titanium valves, DLC coatings, and magnesium covers ensure strength and responsiveness.
Mass-Optimised Layout
Ultra-compact, low-inertia design enhances throttle response and agility.
Dell'Orto Fuel System
44mm throttle body with Keihin injector for class-leading atomisation.
Advanced Engine Management
Athena ECU with GET Power Assist enables standard traction and launch control.
Exedy Clutch + 5-Speed Gearbox
Belleville spring clutch with Brembo hydraulics. Tough, precise transmission.
Efficient Cooling
CFD-optimised flow, Nikasil cylinder coating, optional fan for extreme conditions.
Aluminium Spine Frame
Lightweight central spine with twin cradles. Optimised flex and feedback.
Fabricated Swingarm
Hydroformed main beams reduce weight, maximise rear grip.
D.I.D Final Drive
520 SDH chain with lightweight JT sprockets for reduced mass.
Optimised Linkage System
Developed with race teams for elite-level performance and comfort.
KYB AOS Forks
48mm coil spring forks with compression and rebound adjustment.
KYB Piggyback Rear Shock
Three-way adjustable with 50mm piston and unique hollow mount.
ODI Grips
Half-waffle lock-on grips for pro-level connection.
Neken Yokes + ProTaper Bars
Forged aluminium yokes and carbon-core bars combine feel and control.
Hour Meter
Discrete, integrated tracking of engine hours.
Launch Control
Standard-fit with adjustable levels via WiFi or LC-GPA modules.
Traction Control
Real-time tuning via handlebar-mounted control switch or app. Uses GET GPA strategy.
Dual Engine Maps
Full-power and softer delivery modes. Optional custom maps via app.
Sensor Dashboard
Displays live sensor data, service timing and diagnostics.
D.I.D DirtStar Rims
7000-series alloy with Triumph-designed hubs. Tough and light.
Brembo Brakes + Galfer Discs
24mm/26mm calipers with 260mm front and 220mm rear discs.
Optional Disc Guard
Protects front disc from debris.
Pirelli MX32 Tyres
Race-spec tyres for optimal grip on mid-soft terrain.
