TECH SPECS
Power to Lead
ENGINE & TRANSMISSION
Type
Single Cylinder, 4-stroke, SOHC
Capacity
449.5 cc
Bore
95 mm
Stroke
63.4 mm
Compression
13.1:1
Max power
62.4 PS @ 9500 rpm
Max Torque
49.9 Nm @ 7,000 rpm
System
Dell’Orto throttle body, Athena EMS
Exhaust
Single silencer
Final drive
Chain, 13T/49T
Clutch
Steel, wet, multi-plate, spring (Belleville), hydraulic actuation
Gearbox
5 Speed
CHASSIS
Frame
Spine and double cradle, aluminium
Swingarm
Aluminium fabrication
Front wheel
21 in x 1.6 in
Rear wheel
19 in x 2.15 in
Front tyre
80/100-21
Rear tyre
100/90-19
Front suspension
KYB 48 mm coil spring fork, compression and rebound adjustment, 310 mm wheel travel
Rear suspension
KYB coil, compression adjustment (high and low speed), rebound adjustment, 305 mm wheel travel
Front brakes
Twin, 260 mm disc, Brembo, twin-piston floating caliper (2 x 24 mm pistons)
Rear brakes
Single, 220 mm disc, Brembo, twin-piston caliper (2 x 26mm), OCABS
Instruments
Hour meter, multi-function switch cubes
DIMENSIONS & WEIGHTS
Width
836 mm
Height
1270 mm
Seat height
960 mm
Wheel base
1492 mm
Rake
27.4 °
Trail
116 mm
Wet weight
108.6 kg
Fuel capacity
7 l
STANDARD EQUIPMENT
- D.I.D. DirtStar aluminium wheels
- Dual engine maps
- Exedy Clutch with Brembo Hydraulic Actuation
- Handlebar-Mounted Control Switch
- KYB AOS Suspension (Front & Rear)
- Launch control
- Neken Yokes & Pro Taper ACF Carbon Core Bars
- ODI grips
- Pirelli MX32 Tyres
- Quickshifter
- Sensor Dashboard + Hour Meter
- Traction control
- Athena ECU Engine Management System
Forged König Piston
Lightweight forged aluminium piston provides strength and high-rev durability.
Del West Titanium Valves
Flow-optimised, ultra-light valves allow higher RPMs and improved response.
Advanced Fuel & Air System
Dell'Orto 44mm throttle body and Keihin injector for maximum fuel atomisation.
Quickshifter
Clutchless upshifts from 2nd to 5th gear as standard.
Magnesium Engine Covers
Mass-saving and race-developed for strength, cooling, and easy maintenance.
DLC-Coated Rockers & Cams
Minimises friction for durability and smooth performance at high loads.
Athena ECU
Integrated with GET Power Assist for seamless traction and launch control.
High-Capacity Exedy Clutch
Steel clutch basket and Brembo hydraulics for confident, consistent launches.
Aluminium Spine Frame
Twin cradle design delivers the ideal balance of flex and stability.
Fabricated Swingarm
Hydroformed beams reduce weight while maximising grip and traction.
D.I.D Final Drive
D.I.D 520 SDH chain and JT lightweight sprockets co-developed for further mass improvements.
Optimised Linkage System
Race-developed setup tuned for high-performance suspension feel.
KYB AOS Coil Spring Forks
48mm adjustable forks with enhanced damping and front-end feel.
KYB Rear Shock
Three-way adjustable piggyback shock for controlled landings and drive.
Neken Yokes & ProTaper Bars
Trusted components that deliver comfort, strength, and rider confidence.
ODI Lock-On Grips
Secure, pro-spec connection with comfort-focused design.
Launch Control
Standard-fit with adjustment via LC-GPA module or WiFi app.
Traction Control
Real-time control through handlebar switch or smartphone.
Athena ECU
Controls ignition, launch, traction, and map settings seamlessly.
Sensor Dashboard
Live engine data, service alerts, and diagnostics built in.
Dual Engine Maps
Easily switch between aggressive and manageable power modes. With the optional Accessory Engine Management Unit and the MX Tune Pro app, you can unlock 10 additional engine maps.
Hour Meter
Tracks engine run-time discreetly and accurately.
Optional Disc Guard
Adds durability and protection for race and trail use.
Brembo Brakes + Galfer Discs
Powerful, lightweight braking system designed to perform under pressure.
D.I.D DirtStar Rims
7000-series aluminium rims with race-bred strength and low mass.
Pirelli MX32 Tyres
Factory-fitted mid-soft terrain tyres with top-tier grip.
